Automatic plant labeling machine
Classification:
keywords： Automatic plant labeling machine
E-mail:
Telephone:
Details
Introduction
It is specially designed for labeling various types of cards and applying protective films on the surface of various plastic sheets. It has high precision and the film application is bubble-free. It has the function of automatic product identification and can automatically activate different labeling heads to work according to different products. It can be used in conjunction with various packaging assembly lines.
Features
●Stable card separation: Advanced sorting-reverse dial wheel technology is adopted for card separation, and the card sorting rate is much higher than that of general card separation mechanisms.
●High card separation and labeling speed: For labeling supervision codes on medicine boxes, the stable speed can reach more than 200 pieces per minute.
●Wide application range: It can meet the labeling requirements of various cards and paper items, and is suitable for labeling un-folded cartons.
●Stable labeling accuracy: A top-pressing roller is used to press the workpiece, and the conveying is stable without warping, ensuring the labeling accuracy.
●The ingenious design of the structural combination of the mechanical adjustment part and the label winding makes it convenient to finely adjust the labeling position with 6 degrees of freedom, making the conversion between different products and label winding simple and time-saving.
●Intelligent control, automatic photoelectric tracking, with functions such as no-labeling when there is no object, automatic label correction when there is no label, and automatic label detection, preventing missing labels and label waste.
●High stability: The advanced electronic control system composed of Panasonic PLC + Kunlun Tongtai touch screen + Panasonic needle-shaped photoelectric eye + Leuze electronic label photoelectric eye from Germany supports the 7×24-hour operation of the equipment.
Specification:
| Labeling speed | 30-180 pieces per minute |
| Labeling accuracy | ±1mm |
| Applicable product range | L: 40mm～280mm W: 40mm～200mm H: 20-250mm |
| Applicable label range (Label backing paper) | Width: 20-180mm, Length: 20-250mm |
| Working voltage | 220V, 50Hz |
| Overall dimensions | LxWxH: 2900×900×1400 mm |
