Pre-made Bag Weighing Packing Machine
Classification:
keywords： Pre-made Bag Weighing Packing Machine
E-mail:
Telephone:
Details
The use of packaging range：
1. Solid species: candy, peanut, green bean, pistachio, crystal candy, brown sugar, cookie, cake, daily commodities, cooked food, pickles, puffed food, etc.
2. Granule species: grain, refined monosodium glutamate, granular drug, capsule, seed, condiment, granulated sugar, chicken essence, melon seeds, nuts, pesticide, fertilizer, feed etc.
3. Powder species: milk powder, coffee powder, food additives, condiments, tapioca powder, coconut powder, pesticide powder, fertilizer granules etc.
4. Liquid species: detergent, fruit juice, miller wine, soy sauce, vinegar, drinks etc.
5. Thick liquid species: chilli sauce, tomato sauce, peanut butter, jam, bean sauce etc.
Main performance and features
1. Automatic intermittent rotary preformed bags dispending, opening and closing machine combined with Auger powder filler or automatic Multi-head Combination Weigh Scale Filler, Overhead Work Platform and Z-elevator bulk feeder.
2. Safety guard protected for high speed and consistent production.
3. Heavy duty components and parts are selected for machine durability.
4. Hygienic construction and easy cleaning (Wash down construction on special request)
5. Operators’ friendly design touch-screen control system.
6. Versatile in design, easy to link up with other downstream packaging equipment
such as liquid filler, powder filler, multi heads weigher, metal detector, check weigher, case sealer etc.
7. Innovative and practical solution at reasonable costs.
Safety:
1. No bag - no filling- no sealing, machine alarm.
2. Bag opening miss – no filling – no sealing, machine alarm.
3. Machine stop or alarm when the air pressure is abnormal.
4. Error position display at the control panel.
5. Control panel locate on the right-side top of the machine.
6. Outside of the machine and all the parts which touch production all made by stainless steel.
7. There are several safety doors made by aluminum Profile Frame.
8. The doors are equipped with safety proximity sensors.
9. Machine surface can be washed by water and brushed by cloth.
Specifications and parameter:
| No. of working station | Eight-working Station |
| Bag type | All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock recloseable bags, stand-up pouch with or without spout etc. |
| Bag size(mm) | W:80-200 L:100-300 |
| Filling volume(g) | 10-1500g |
| Capacity | 25-60bags/min depending on type of product and packaging materials used |
| Accuracy | Error≤±1% |
| Total power consumption(KW) | 5KW |
| Application | Candy, biscuit, peanut, cookies, pistachio, crystal candy, brown sugar, daily commodities, cooked food, pickles, puffed food etc. |
| Optional equipment | Dosing assembly, materials bulk feed system, special down stream attachments etc. |
