Ribbon Blender
Classification:
keywords： Ribbon Blender
E-mail:
Telephone:
Details
Structure and features
By the u-shaped containers, ribbon mixing blades and transmission parts; U ChangTi cylinder structure, ensure the be mixed materials (powder, semiliquid) in the cylinder body of the small resistance movement. Positive and negative rotation ribbon is installed on the same horizontal axis, forming a low power efficient mixed environment, spiral strip blades made of double layer or three layers, the outer spiral material from two side to the central pool, on both sides of the inner spiral material from the central to transport, can make the material more vortices in the flow. Accelerate the mixing speed, improve mixing uniformity.
Discharging mode
Big open structure, using pneumatic materials has the advantages of fast discharging, no residual; Adopt high fineness of materials or semiliquid material using manual butterfly valve or pneumatic butterfly valve. Configurable heating or cooling jacket. Heating mode has electric heating and heat conduction oil heating in two ways. Cooling process can be directly to infuse water jacket and clip hot swap area is large, the cooling speed. Small type mixer adopts reducer direct mode, simple structure, high operating reliability, maintenance is convenient. Large number mixer adopts pulley drive the cycloid speed reducer drive, belt
transmission of elastic connection has the advantage of the overload protection when driving part.
Application Scope
Used in pesticides, veterinary drugs, food, chemical, biological, breeding industry, ceramics, refractory material, plastic, compound fertilizer, such as solid-solid (powder and powder) solid-plasma (i.e., powder and rubber slurry) mix, specifically adapted to viscous material mix.
Technical Specifications
| Model | Total | Load | Power(KW) | Dimensions(mm) | Weight (kg) |
| WLDH-100 | 100 | 0.4-0.8 | 3 | 1190x740x770 | 330 |
| WLDH-300 | 300 | 0.4-0.8 | 4 | 2030x630x980 | 720 |
| WLDH-500 | 500 | 0.4-0.8 | 7.5 | 2320x730x1130 | 980 |
| WLDH-1000 | 1000 | 0.4-0.8 | 11 | 2800x920x1320 | 1700 |
| WLDH-1500 | 1500 | 0.4-0.8 | 11 | 3180x1020x1550 | 1800 |
| WLDH-2000 | 2000 | 0.4-0.8 | 15 | 3310x1120x1640 | 2100 |
| WLDH-3000 | 3000 | 0.4-0.8 | 18.5 | 3750x12290x1820 | 3000 |
| WLDH-4000 | 4000 | 0.4-0.8 | 22 | 4220x1400x1990 | 3980 |
| WLDH-5000 | 5000 | 0.4-0.8 | 22 | 4220x1500x2100 | 4620 |
