Product Series
SMI-700S Digital Metal Detector
Classification:
keywords: SMI-700S Digital Metal Detector
E-mail:
Telephone:
Details
SMI-700S Digital Metal Detector is a specialized metal detector that aims to detect and reject metal within tablets, capsules or granules. Outfitted with imported control system which is of high precision, high sensitivity and high stability, this machine can be applied to detecting and removing magnetic and non-magnetic metal foreign bodies in tablets and capsules, and even small metal chips and metal wires embedded in the product. The machine can detect 100% of running materials, reduce material loss, avoid drug pollution caused by metal foreign bodies, and keep the pollution to the lowest limit.
Working principle:
The material passes through the detection coil and slides down due to the angle of inclination. Once metal is detected, the rejecting cover plate starts to work to reject the material containing metal impurities from the waste port.
Technical parameter:
Model | SMI-700S |
Caliber of feeding inlet(mm) | Φ35 |
Detection accuracy | feΦ0.3mm; sus:0.6mm; Nofe:0.5mm |
Capacity | 10,000-15,000 pcs/min |
Working voltage | AC220V±10%, 50-60Hz (Customizable AC110V/ AC380V) |
Ambient temperature(℃) | -10 - +80 |
Discharge time | 0.3~5s (Adjustable) |
Compressed air(Bar) | 4~7 |
Product Features and Advantages
●The special structure design can effectively avoid the interference of external factors such as vibration, noise and product effects;
●German technology, ultra-high detection accuracy, metal detector specially designed for medicine and health products;
●Sheet-like and long-fiber products will not block the rejection equipment;
●Ultra-high working frequency ensures the best detection accuracy and performance;
●Specially used to detect magnetic and non-magnetic metals in flakes, powders, particles, fibers and wet materials for drug separation;
●A variety of calibers are available, the models meet all practical applications;
●Detector head: 316 stainless steel surface, protection grade IP65
●Rejection: The equipment is equipped with a 316 stainless steel with Pushing Board Reject System, which is easy to remove and clean. The elimination agency can meet FDA and USDA certification requirements.
●Remove metal impurities online to ensure the normal operation of the production line. Manually lift the height of the rack and fine-tune the tilt angle, which is easy to move and clean.
●Unique accuracy can detect tiny metal objects in medicines, and the processing
●speed can reach about 15,000 grains per minute;
●Comply with HACCP, GMP, GAMP, FDA, IFS, ISO9001 and other related certification standards.
