SWJJ Seamless Softgel Machine
Classification:
keywords： SWJJ Seamless Softgel Machine
E-mail:
Telephone:
Details
Machine Introduction
The model SWJJ softgel machine is composed of systems such as the medicine supply system, gelatin supply system, pulse cutting system, cooling liquid circulation system, and refrigeration system.
Application
The filling materials of the SWJJ softgel machine are oily substances insoluble in water (cod liver oil, vitamins A, D, E, K, traditional Chinese medicine), vegetable oils, flavors, smoking cessation formulas, nutritional agents, and so on. It can be widely applied to the mass production of seamless soft gelatin capsules in industries such as health products, pharmaceuticals, food, and cosmetics, and it is a softgel equipment for the production of seamless softgel.
Features
●Softgel can be formed by dropping pills, filled, and sealed instantaneously without the need for molds.
●It has low material consumption and a high yield rate of finished products.
●The filling amount of the pills is accurate, and the quality of the soft gelatin capsules is excellent.
●The main machine is controlled by PLC, with parameter display on a 10.1-inch touch screen. It is easy to operate, has a high degree of automation, a compact structure, and occupies a small floor area.
●The entire production line is easy to clean and fully complies with the relevant GMP standards of the country.
Technical Parameters
| Working voltage(V) | 220/380 |
| Power supply(kw) | 4.5 |
| Temperature control | softgel capsule liquid, core material, oil bath, cooling, refrigeration, drip head |
| Product speed | 4-20 Pcs/Second |
| Weight and diameter of soft capsule | 5-600mg (dia 2-10mm) |
| Volume of content tank | ≦10L(Customizable) |
| Rubber tank volume(L) | Standard 60L |
| Weight(kg) | 280kg |
| Machine dimension(mm) | 710×860×1900 |
