Details
TDP SINGLE TABLET PRESS MACHINE
TDP single punch tablet press machine, which could press the power material to tablet, could be widely used in the pharmacy factory, chemistry factory, hospital and R & D bureau. This machine is with good performance, strong suitability, simple operation, easily repair, small cubage, light. Even under the conditions or power cut ,hand swing is available .Compare to original TDP model press machine ,it is enlarged the machine intensive and engine power with bigger strength. In the meantime enlarge the filling depth, hence to expand the specification range of tablet. Therefore this machine can meet the demand of different kinds of Chinese traditional medicine and Western medicine and other similar product's requirement. It's deeply welcomed by our customers in different field.
Future
1. This machine is an undersized desktop stamping tablet machine which is driven by
electrical motor, which can stamp out all kinds of tablets continuously.
2. This machine can stamp all kinds of granules and coarse powder into round or
special-formed tablets, which are indicated for labs or for producing in small
quantities all kinds of tablets, pastilles, calcium, special-formed tablets etc.
3. This machine is not indicated for stamping large-granule solid, wet or
micro-powder.
4. The simple structure, convenient operation and high automation make this machine
suitable for stamping all forms of tablets
Main Technical Data
| Item | TDP-1.5 | TDP-5 | TDP-6 |
| Max .press strength(KN) | 15 | 50 | 60 |
| Max .tablet diameter(mm) | 12 | 20 | 25 |
| Max .filling depth(mm) | 12 | 18 | 16 |
| Productive capacity(Pcs/Hour) | 4700 | 4500 | 4000 |
| Motor power(kw) | 0.25 | 0.55 | 1.1 |
| Turning speed(r/min) | 1400 | 1400 | 1400 |
| Weight (kg) | 65 | 125 | 150 |
| Length*Width*Height(mm) | 570x380x630 | 650x440x650 | 700x500x900 |
