Uphill Elevating Tablet Dedusting Machine SZS-750
Classification:
keywords： Uphill Elevating Tablet Dedusting Machine SZS-750
E-mail:
Telephone:
Details
Purpose:
It is used for up-rotating transmission and dust removal of tablets, and can be easily connected to the tablet machine. The dust removal process uses vibration, compressed air and vacuum to remove dust from the tablets. The vibration of the stainless-steel turret makes the tablets move upward along the spiral channel and shake off the dust at the same time. At the same time, the compressed air blows the dust into the central dust collector.
| Model | SZS-750 |
| Capacity(pcs/hour) | 800,000pcs/h（depending on dia 6mm) |
| Tablet diameter(mm) | dia 3-25 |
| Inlet height(mm) | 825-1005 |
| Outlet height(mm) | 1230-1410 |
| Dedusting distance(m) | 7.5 |
| Compressed air | 0.1m3/h (0.05MPa) |
| Vacuum cleaning | 2.7m3/h (-0.1MPa) |
| Power supply | 110V 60Hz / 220V 50Hz 0.1kw |
| Outline dimensions(mm) | 550*550*(1365-1545) |
| Machine weight(kgs) | 80 |
